The Different Types of Static Mixing Nozzles

Q: What is the difference between standard and Quadro static mixer nozzles?

Standard mixers are the oldest technology in two-part adhesive dispensing. These nozzles are round and come in a wide range of connection types. They typically require longer nozzles and more mixing elements to create the same mixing quality as Quadro mixers. Quadro mixers are the newest technology for two-part dispensing and are square in shape. They allow for more complete mixing in a shorter nozzle so users can get closer to their substrates when dispensing. There is also less wasted adhesive left over in the nozzle.

Updated: August 15, 2024

Jump to:

Types of Static Mixer Nozzles
Choosing the Right Type of Static Mixer
Product Recommendations
Choosing a Static Mixer Nozzle Based on Adhesive

Disposable static mixers are a great dispensing tool for two-part adhesives with different ratios. Also known as static mix nozzles, these accessories are used to mix the components as they make their way down a chamber before being dispensed. The mixing process often activates the adhesive or material being dispensed and begins the adhesion process.

Because there are so many different adhesive ratios and cartridge types, choosing the right type of static mixer can get a bit confusing, but we want to help.

Types of Static Mixer Nozzles

There are several kinds of static mixers available in different forms. Each type of glue nozzle is suited to particular applications and has unique advantages and disadvantages.

In-line mixers are a type of nozzle mixer where components are placed as a permanent part of the dispensing line. Static dynamic mixers are a type of glue mixing nozzle that has moving parts but is not powered.

Disposable static mixers take the form of a nozzle that attaches to either meter mix and dispense (MMD) or hand-held dispensing equipment. Their internal components can vary greatly depending on the needs of the application. The most common are the helical type and the box chamber type. Disposable static mixers are designed to be thrown away after use which can be cost effective compared to the flushing and cleaning necessary in non-disposable mixers. They also make sense for equipment which will handle multiple adhesive types.

Disposable Static Mixer Connection Types

There are a number of different ways to connect a disposable static mixer to your cartridge or meter mix equipment. The two most common connection types of static mixers are Bell and Bayonet.

Bell Mixer – This type of static mixer connection will attach to a glue gun or more commonly, meter mix equipment using a retaining nut. After the nozzle is attached, the nut will slip over the top and screw into the equipment or gun.

Bayonet Mixer – This mixer is a twist and lock connector that is common for cartridge glue guns of all sizes.

Types of Disposable Static Mixing Tips

There are also several different static mixer tips to fit different dispensing needs. The three most common are stepped, tapered, and Luer lock.

Stepped Tip – These tips can be cut at various points to increase the size of the adhesive bead being dispensed. The ends don't require any adapters or needles to adjust bead size. The downside comes when fine dispensing is required.

Tapered Tip - Tapered tips are not adjustable, and for the most part, will not accept needles or fine tips. This is a simple and easy way to dispense common bead sizes.

Luer Lock - Luer lock tips give users the ability to add adhesive needles or tips for precise dispensing. Often, this type of disposable nozzle style requires an adapter like the Sulzer Mixpac LA 05-00 Luer lock adapter. After the adapter is attached, the needles and tips can easily be locked into place.

Choosing the Right Type of Static Mixer

You want to ensure that you get the right mixer for your specific requirements. The type of static mixer nozzle you need will depend on a number of different factors.

Type of Connection- Different cartridges and dispensing equipment use different connectors. Users should always start with the type of connection required.
Dispensing Equipment - One key consideration is if the adhesive will be dispensed by a machine or a hand-held applicator. Disposable mixers are more frequently used for hand-held equipment and are compatible with various cartridge sizes. Machine dispensing applications may also use static mixers if adhesives are being changed or other mixing options aren't feasible.
Shot Size - A larger shot size/faster dispensing will require fewer mixing elements and a larger diameter opening. Because a larger diameter usually means less efficient mixing, a balance is required between the two. Smaller shot sizes require more mixing elements and a smaller diameter for an ideal mix.
Adhesive Characteristics - Thicker adhesive components require larger diameter openings to flow and mix properly. The difference between component viscosities will also affect the number and type of elements needed.
Size- You will also need to figure out what size cartridge or meter mix equipment you will be dispensing from. This will help determine what type of mixer nozzle you need.

Product Recommendations

Even if you know what type of static mixer you are looking for, there are several similar products available on the market. As experts in the adhesive industry, we are sharing some of our recommendations for products based on various properties.

Jump to:

For 50 ml Cartridges
For 200, 400, & 600ml Cartridges
For Meter Mix Dispensing
For Rotary Machine Dispensing Equipment

For 50 ml Cartridges

50ml cartridges for are popular and a great way to mix and dispensing two-part adhesives for low volume applications or those that require lightweight, precise application of material. There are two types of 50ml cartridges, each of which require a different type of mixer nozzle.

Bayonet Static Mixers for 50ml Cartridges (A-System)

Sulzer Mixpac 50ml A-System 1:1 Cartridge

Cartridge System

The Sulzer Mixpac A-System 50ml cartridge kit comes in a variety of cartridge types and mixing ratios. They can be dispensed with most standard cartridge guns and provide a top of the line solution for two-part dispensing.

Mixing Nozzle

The Infinity Bond Bayonet static mixing nozzle is the go-to mixer for two-part 50ml cartridges. High quality and low cost make this static mixer the perfect match when dispensing epoxies, acrylics, urethanes and more.

Sulzer Mixpac MAH Static Mixer - All Sizes

Mixing Nozzle

The Sulzer Statomix MAH bayonet mixing tip has a twist and lock mount for 1:1 and 2:1 dispensing. Locking the MAH mixer into place automatically aligns the first element when using the Sulzer A System Kit.

B-System Mixers for 50ml Cartridges

Sulzer Mixpac B-System 50ml 1:1 Cartridges

Cartridge System

The Sulzer Mixpac B System 50 ml cartridge system offers a built-in piston retention for easier use. The rectangular back on the cartridge allows it to fit standard 50ml cartridge guns and it comes in a variety of configurations to better fit users' dispensing needs.

Sulzer Mixpac MBH 05-20T disposable static mixer nozzle

Mixing Nozzle

The Sulzer Mixpac MBH 05-20T static mixer is a high quality mixer for dispensing 2:1 adhesives and materials. It utilizes a stepped tip giving users the ability to adjust bead size by cutting the tip. This mixer has 20 elements with a 5.4 mm element diameter and a twist and lock system for connecting to your cartridge.

Sulzer Mixpac MBQ disposable static mixer nozzle

Quadro Nozzle

The Sulzer Mixpac MBH 05-20T static mixer allow for optimal mixing between 1:1 and 2:1 two-part epoxies, silicones, acrylics, urethanes and more. The Quadro form lets users get closer to the materials they are bonding.

Sulzer Mixpac MBH 05-20T Static Mixer Nozzle

Twist and Lock Nozzle

The Sulzer Mixpac Statomix MBHX mixer nozzle can be used with the Sulzer B system components for 4:1 and 10:1 dispensing. It uses a twist and lock system separate outlets for the A and B materials ensuring there is no cross-contamination.

For 200, 400, & 600ml Cartridges

Larger cartridges are a great option for medium to high volume dispensing applications. There are two types of larger cartridges and each requires a different type of mixer nozzle.

C System Nozzles for 200ml Cartridges

Sulzer Mixpac C-System 200ml 1:1 Cartridges

Cartridge System

The Sulzer Mixpac C System 200 ml cartridge system can be filled with most two-part adhesive materials that need to be mixed to activate. A nozzle can then be attached to the cartridge system and dispense the material using standard 200ml manual or pneumatic guns.

Mixing Nozzle

The Infinity Bond 160-824 static mixer nozzle is the top-selling mixer for standard 1:1 or 2:1 adhesive dispensing from 200ml or 400ml cartridges. It is a bell mixer with a stepped tip allowing it to be cut at different sizes to adjust dispensing volume.

Mixing Nozzle

The Infinity MCH 10-24T static mixer is equal (or higher) in quality to its name brand equivalents but offers exceptional cost savings. This mixer has a bell connection and stepped mixing outlet allowing it to be cut to adjust the dispensing volume.

F System Static Nozzles for 200ml Cartridges

Sulzer Mixpac F-System 200ml 1:1 Cartridge

Cartridge System

The Sulzer Mixpac F System 200ml cartridge system allows for medium to high volume dispensing and includes self venting lip seal pistons for easier extrusion as well as preassembled nose plugs. This cartridge is available in two different materials to better fit the materials being filled and dispensed.

Mixing Nozzle

The Sulzer MFH static mixer features a unique outlet that connects the nozzle to the cartridge. This patented design is unique to Sulzer allowing the two materials to enter the nozzle through their own orifice completely eliminating the possibility of cross contamination. The MFH mixers are used for dispensing 1:1 and 2:1 ratio adhesives.

Sulzer Mixpac MFQX disposable static mixer nozzle

Quadro Nozzle

The Sulzer Mixpac Quadro MFQX static mixers allow for 4:1 and 10:1 adhesive dispensing. They give optimal mixing in a smaller footprint than traditional mixers allowing users to work more closely with the materials they are bonding while still keeping A and B parts from mixing prematurely and clogging the mixer tip.

F System Nozzles for 400ml Adhesive Cartridges

Sulzer Mixpac F-System 400ml 1:1 Cartridge

Cartridge System

The Sulzer Mixpac F System 400ml cartridge sytem allows for medium to high volume dispensing. It also includes self venting lip seal pistons for easier extrusion and is available in two different materials.

Mixing Nozzle

What makes the Sulzer MFH static mixer unique is the outlet that connects the nozzle to the cartridge. It allows the two materials to enter the nozzle through their own orifice. This design eliminates the possibility of cross contamination.

Quadro Nozzle

The Sulzer Mixpac Quadro MFQX static mixers allow for 4:1 and 10:1 dispensing. They have a smaller footprint than traditional mixers so users can work closer to their materials without mixing the two components.

For Meter Mix Dispensing

Meter Mix Dispensing

Meter mix equipment is perfect for high volume applications, and Bell static mixing nozzles are a high quality, low cost solution for a wide variety of these applications.

Mixing Nozzle

One of the most tried and true mixers for two-part dispensing with meter mix equipment, the Sulzer MS Series static mixer offers a high quality, low cost solution for a wide variety of applications.

Sulzer Mixpac ME Series Static Mix Nozzle

Mixing Nozzle

The Sulzer ME Series static mixer nozzles are a tried and true mixer for dispensing adhesive with meter mix equipment. The ME nozzle has a stepped tip which can be cut to adjust the dispensing volume and is available in many different element and diameter configurations.

The MS Series has an inner diameter on the bell housing of .657 inches while the ME Series mixer has an inner diameter on the bell housing of .625 inches. This is essentially the only difference between the two.

For Rotary Machine Dispensing Equipment

Nozzles for rotary machine dispensing equipment are designed for use with specialty meter mix and dispensing equipment. Static nozzles provide inexpensive solutions for the dynamic mixing, with elements that rotate within the nozzle attachment.

Mixing Nozzle

The Sulzer Mixpac Statomix MSR Series (formerly MR Series) mixer is a disposable plastic mixer designed for use with meter mix and other dispensing equipment. The MSR Series is especially good at dispensing low viscosity adhesives like hard to mix foam and urethane elastomers.

Choosing a Static Mixer Nozzle Based on Adhesive

The materials you are mixing directly determine the range of elements needed to mix the materials into a homogenous material. Some materials are considerably more difficult to mix than others, so it is crucial that you have the appropriate amount of elements in your mixer to get the mix you need.

Some common materials you will likely be working with include acrylic, epoxy, poly-sulfide, PU foam, silicone, and urethane. Typically, the element range needed for each of these separate materials is as follows:

Material	Range of Elements
Acrylic	8-20 Elements
Epoxy	15-24 Elements
Polysulfide	24-32 Elements
PU Foam	10-24 Elements
Silicone	20-30 Elements
Urethane	24-36 Elements

There are two factors that can indicate you should use a number toward the higher range. The first is the viscosity of the materials. If the two elements have very different viscosities (i.e. material A is 5,000 cps and material B is 150,000 cps), you will likely need to use the higher number of elements. The second is the material ratio. If you are dealing with a mixing ratio of 7:1, for example, a higher number of elements will be needed to achieve a pure, homogenous mix.

Find the Right Type of Static Mixing Nozzle

Choosing the best static mixer for your application is a process. While you may now have a better understanding of the different types of static mixers, you may still want to consult one of our adhesive experts.You can also visit our collection of static mixing nozzles and shop for yourself.
