Understanding the Old vs New Sulzer Mixpac Static Mixer Part Numbers
Sulzer Mixpac continues to add static mixer technology and products to their portfolio but on some of the old 'tried and true' static mixers, the only thing that has changed is the part number. It can be a little confusing searching for a part number that has changed or no longer exists so we have put together a simple comparison of the old vs new static mixer nozzle part numbers from Sulzer Mixpac.
Shop All Sulzer Mixpac Static Mixers
Check out the table below to find a complete list of old Sulzer sku and their new counterparts. Each series has it's own header to help you get to the correct section you are looking for. The part numbers are similar in most cases, however the Quadro Series Static Mixer skus were modified quite a bit. If you have any additional question please contact us 855-437-7700.
Sulzer Mixpac Mixer Technologies
Quadro Mixer Technology:
Innovative new mixer design, the Quadro mixer allows the nozzle to be very compact & short. The unique Quadro design offers mixing elements that are doubled. The geometry of this mix nozzle in combination with the square shape makes this ideal for layer forming. As this mixer is extremely short and a very low pressure drop in comparison to other mixers.
Statomix Mixer Technology:
Offers specifically designed helical mixers available in different length and diameters to meet requirement of dispensing machines.
Mixpac Mixer Technology:
Built with a patented interface to ensure a clean, leak-free, and safe connection, these helical mixers work with systems K, B and F.
| Old Part Numbers | New Part Numbers |
| Static Mixers - Sulzer Quadro Series | |
| 300-002 | MCQ 05-24L |
| 300-006 | MCQ 07-24T |
| 300-026 | MAQ 05-24L |
| 300-028 | MAQ 05-16L |
| 300-341 | MCQ 07-24T-12 |
| 300-364 | MGQ 10-19D-21 |
| 300-375 | MCQ 08-32T |
| 300-377 | MCQ 10.7-32T |
| 300-385 | MCQ 10-24T-24 |
| 300-391 | MAQ 05-16L-12 |
| 300-403 | MAQ 05-24L-12 |
| 300-405 | MAQ 05-16L-13 |
| 300-408 | MGQ 10-19A |
| 300-415 | MGQ 10-24T-12 |
| 300-43 | MCQ 10-24T-14 |
| 300-453 | MGQ 08-20T |
| 300-455 | MCQ 08-24T |
| 300-461 | MGQ 08-24T |
| 300-466 | MGQ 08-24D-12 |
| 300-491 | MAQ 05-16L-01 |
| 300-494 | MGQ 10-19D-11 |
| 300-496 | MCQ 10-24T-01 |
| 300-497 | MGQ 10-24D |
| MBQ 5.3-16-SPE | MBQ 05-16L |
| MBQ 5.3-24-SPE | MBQ 05-24L |
| MBQX 5.3-16-S | MBQX 05-16L |
| MBQX 5.3-24-S | MBQX 05-24L |
| MFQ 10.7-24 | MFQ 10-24T |
| MFQ 5.3-16 | MFQ 05-16L |
| MFQ 5.3-24 | MFQ 05-24L |
| MFQ 7.5-24 | MFQ 07-24T |
| MFQ 8.7-24 | MFQ 08-24T |
| MFQX 10.7-24 | MFQX 10-24T |
| MFQX 5.3-16 | MFQX 05-16L |
| MFQX 5.3-24 | MFQX 05-24L |
| MFQX 7.5-24 | MFQX 07-24T |
| MFQX 8.7-24 | MFQX 08-24T |
| Static Mixers - Sulzer MA Series | |
| MA 0517-0413 | MAH 0517-0413T |
| MA 3.0-07-S | MAH 03-07S |
| MA 3.0-13-S | MAH 03-13S |
| MA 3.0-17-S | MAH 03-17S |
| MA 4.0-13-D | MAH 04-13D |
| MA 4.0-13-S | MAH 04-13S |
| MA 4.0-17-D | MAH 04-17D |
| MA 4.0-17-S | MAH 04-17S |
| MA 5.4-07-S | MAH 05-07T |
| MA 5.4-13-D | MAH 05-13D |
| MA 5.4-13-S | MA 5.4-13-S |
| MA 5.4-13-S | MAH 05-13T |
| MA 5.4-17-S | MAH 05-17T |
| MA 5.4-21-S | MAH 05-21T |
| MA 6.3-12-D | MAH 06-12D |
| MA 6.3-12-S | MAH 06-12T |
| MA 6.3-17-S | MAH 06-17T |
| MA 6.3-21-L | MAH 06-21L |
| MA 6.3-21-S | MAH 06-21T |
| Static Mixers - Sulzer MB Series | |
| MB 3.2-12-D | MBH 03-12D |
| MB 3.2-12-S | MBH 03-12S |
| MB 3.2-16-D | MBH 03-16D |
| MB 3.2-16-L | MBH 03-16L |
| MB 3.2-16-S | MBH 03-16S |
| MB 4.2-12-D | MBH 04-12D |
| MB 4.2-16-D | MBH 04-16D |
| MB 4.2-16-S | MBH 04-16S |
| MB 5.4-06-S | MBH 05-06T |
| MB 5.4-12-D | MBH 05-12D |
| MB 5.4-14-D | MBH 05-14D |
| MB 5.4-16-S | MBH 05-16T |
| MB 5.4-20-S | MBH 05-20T |
| MB 6.5-11-D | MBH 06-11D |
| MB 6.5-16-S | MBH 06-16-T |
| MB 6.5-20-S | MBH 06-20T |
| MB 7.5-11-D | MBH 07-11D |
| MB 7.5-11-D | MBH 07-11D |
| MBX 3.2-16-S | MBHX 03-16S |
| MBX 4.2-16-D | MBHX 04-16D |
| MBX 4.2-16-S | MBX 4.2-16-S |
| MBX 5.4-12-D | MBHX 05-12D |
| MBX 5.4-16-S | MBHX 05-16T |
| MBX 5.4-20-S | MBHX 05-20T |
| MBX 6.5-16-D | MBHX 06-16D |
| MBX 6.5-16-S | MBHX 06-16T |
| MBX 6.5-20-S | MBHX 06-20T |
| Static Mixers - Sulzer MC Series | |
| MC 05-18 | MCH 05-18T |
| MC 05-24 | MCH 05-24T |
| MC 05-32 | MCH 05-32T |
| MC 06-18 | MCH 06-18T |
| MC 06-24 | MCH 06-24T |
| MC 06-32 | MCH 06-32T |
| MC 08-18 | MCH 08-18T |
| MC 08-24 | MCH 08-24T |
| MC 08-32 | MCH 08-32T |
| MC 1008-12-T | MCH 1008-12S |
| MC 1008-18-A | MCH 1008-18S |
| MC 1008-18-T | MCH 1008-18S |
| MC 10-18 | MCH 10-18T |
| MC 10-20-A | MCH 10-20D |
| MC 10-24 | MCH 10-24T |
| MC 10-24-A | MCH 10-24D |
| MC 10-32 | MCH 10-32T |
| MC 13-12 | MCH 13-12T |
| MC 13-18 | MCH 13-18T |
| MC 13-24 | MCH 13-24T |
| MC 13-32 | MCH 13-32T |
| MC 15-12-A | MCH 15-12-30 |
| MCX 08-18 | MCHX 08-18T |
| MCX 08-24 | MCHX 08-24T |
| MCX 10-12 | MCHX 10-12T |
| MCX 10-18 | MCHX 10-18T |
| MCX 10-24 | MCHX 10-24T |
| MCX 13-12 | MCHX 13-12T |
| MCX 15-12-A | MCHX 15-12-30 |
| Static Mixers - Sulzer ME Series | |
| ME 05-24 | ME 05-24T |
| ME 05-32 | ME 05-32T |
| ME 06-24 | ME 06-24T |
| ME 06-32 | ME 06-32T |
| ME 06-48 | ME 06-48T |
| ME 08-24 | ME 08-24T |
| ME 08-32 | ME 08-32T |
| ME 1012-0832 | ME 1012-0832T |
| ME 10-24 | ME 10-24T |
| ME 10-32 | ME 10-32T |
| ME 1312-1032 | ME 1312-1032T |
| ME 13-24 | ME 13-24T |
| ME 13-24-L | ME 13-24T-02 |
| ME 13-32 | ME 13-32T |
| ME 13-32-L | ME 13-32T-02 |
| MEF 06-24 | MEF 06-24T |
| MEF 06-32 | MEF 06-32T |
| MEF 08-24 | MEF 08-24T |
| MEF 08-32 | MEF 08-32T |
| MEF 10-24 | MEF 10-24T |
| MEF 10-32 | MEF 10-32T |
| MEF 13-18 | MEF 13-18T |
| MEF 13-24 | MEF 13-24T |
| MEFX 06-18 | MEFX 06-18T |
| MEFX 08-18 | MEFX 08-18T |
| MEFX 10-18 | MEFX 10-18T |
| MEFX 13-18 | MEFX 13-18T |
| MEFX 13-24 | MEFX 13-24T |
| Static Mixers - Sulzer MF Series | |
| MF 06-18 | MFH 06-18T |
| MF 06-24 | MFH 06-24T |
| MF 06-32 | MFH 06-32T |
| MF 08-18 | MFH 08-18T |
| MF 08-24 | MFH 08-24T |
| MF 08-32 | MFH 08-32T |
| MF 10-18 | MFH 10-18T |
| MF 10-24 | MFH 10-24T |
| MF 10-32 | MFH 10-32T |
| MFX 06-18 | MFHX 06-18T |
| MFX 06-24 | MFHX 06-24T |
| MFX 06-32 | MFHX 06-32T |
| MFX 08-18 | MFHX 08-18T |
| MFX 08-24 | MFHX 08-24T |
| MFX 08-32 | MFHX 08-32T |
| MFX 10-18 | MFHX 10-18T |
| MFX 10-24 | MFHX 10-24T |
| MFX 10-32 | MFHX 10-32T |
| MG 08-06 | MGH 08-06S |
| Static Mixers - Sulzer MR Series | |
| MR 06-12 | MSR 06-12T |
| MR 08-12 | MSR 08-12T |
| MR 10-12 | MSR 10-12T |
| MR 13-12 | MSR 13-12T |
| Static Mixers - Sulzer MS Series | |
| MS 05-24 | MS 05-24T |
| MS 05-32 | MS 05-32T |
| MS 06-24 | MS 06-24T |
| MS 06-32 | MS 06-32T |
| MS 06-48 | MS 06-48T |
| MS 06-56 | MS 06-56D |
| MS 06-56-L | MS 06-56-L |
| MS 08-24 | MS 08-24T |
| MS 08-32 | MS 08-32T |
| MS 1012-0832 | MS 1012-0832T |
| MS 10-18 | MS 10-18T |
| MS 10-24 | MS 10-24T |
| MS 10-32 | MS 10-32T |
| MS 1312-1032 | MS 1312-1032T |
| NEW | MS 13-12G |
| NEW | MS 13-18G |
| MS 13-24 | MS 13-24T |
| MS 13-24-L | MS 13-24T-02 |
| MS 13-32 | MS 13-32T |
| MS 13-32-L | MS 13-32T-02 |
| MS 13-32-M | MS 13-32G-01 |
| Static Mixers - Sulzer MX Series | |
| MX 0517-0413 | MAHX 0517-0413 |
| MX 3.0-17-S | MAHX 3.0-17-S |
| MX 4.0-17-S | MAHX 04-17S |
| MX 5.4-17-S | MAHX 05-17T |
